Prepainted Color Painted Galvanized Steel Coil PPGL

Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Min. Order: 25 Metric Ton
Delivery Time: 30 Days

Additional Info


Packaging: Seaworthy standard export packing . CARDBOARD SLEEVES, STEEL SHEET WRAPPED OUTSID, FIXED BY STEEL BELT.

Productivity: 300000

Brand: XINGHAN

Transportation: Ocean,Land

Place of Origin: CHINA

Supply Ability: 500000

Certificate: ISO 9001:2008/SGS/BV

Port: TIANJIN, CHINA,QINGDAO


Product Description

Versatility

Prepainted galvanized steel coil has proven to be extremely versatile for the manufacturing industry. Any business involved in the production of such utilitarian products as metal roofing, wall panels, garage doors, beverage cans, automotive parts, home appliances, HVAC duct work and outer panels, food service equipment and office furniture.

Quality

One of the biggest advantages of pre-painted galvanized steel coil is the impeccable quality of its coating, designed to produce uniform results. Manufacturers have their choice of metals, such as coils of cold-rolled steel, zinc-steel, aluminum, brass, copper and stainless steel, in addition to a variety of pretreated coatings, including vinyls, epoxies, fluorocarbons, dry lubricants, acrylics and plastisols. Coatings can be applied to both sides of the metal, resulting in a prefinished metal offering a high-quality finish and consistency in color, thickness, texture and performance.

Safety

Manufacturing customers who switch to prepainted galvanized steel coil love the environmental benefits that this choice offers their manufacturing plant. Not only does this superior product make the plant more environmentally friendly, it eliminates such imperfections as uneven applications and oil and dirt residue.

Longevity

Using galvanized steel coil that has been prepainted for any manufacturing process ensures metal parts that have been uniformly treated with two coats of paint, ensuring a tight bonding that resists corrosion and enhances long-term durability. Research studies comparing raw metals that have been treated at the manufacturing plant compared to prepainted metal parts have proven that using prepainted metal coils not only ensure a superior, corrosion-resistant product, but also outperforms any metal product that was treated or painted at

the plant.

Prepainted Color Painted Galvanized Steel Coil PPGL


Pre painted galvanized steel coils (PPGI)

CONTENTS

PREPAINTED GALVANIZED – PPGI

PREPAINTED GALVALUME – PPGL

BASE METAL

GALVANIZED

GALVALUME / ALUZINC

STANDARDS

JIS G 3312-CGCC, CGC340-570,( 57534855,G550),

JIS G 3312-CGLCC, CGLC340-570,( 57534856,G550),

ASTM A -755M CS-B, SS255-SS550

ASTM A -755M CS-B, SS255-SS550

THICKNESS

0.14~2.0 mm

0.14~2.0 mm

Width

750~1500 mm

750~1500 mm

Coil ID

508/610 mm

508/610 mm

Substrate

Soft, Medium, Hard

Soft, Medium, Hard

Coating Mass

Z 40-275 (g/m2)

AZ 40-150 (g/m2)

Paint Systems

Primers: Epoxy,  PU

Primers: Epoxy,  PU

Top Coating:

Top Coating:

Polyester (RMP/PE)

Polyester (RMP/PE)

Silicon Modified Polyester (SMP)

Silicon Modified Polyester (SMP)

Poly Vinyl Di Flouride (PVDF)

Poly Vinyl Di Flouride (PVDF)

Back Coating: Epoxy, Polyester, PU

Back Coating: Epoxy, Polyester, PU

Coating

20 – 50 Microns

20 – 50 Microns

Colours

As Per RAL Chart/Customer requirements.

As Per RAL Chart/Customer requirements.

Surface Finishes

Glossy and Matte

Glossy and Matte

Cut to length

200mm-5000mm

200mm-5000mm

Capacity

1,500,000.00 Ton / year

1,500,000.00 Ton / year

Packing

Sea Worthy Export Packaging

Sea Worthy Export Packaging

Loading Port

Tianjin Port/Jingtang Port/Shanghai Port

Tianjin Port/Jingtang Port/Shanghai Port

Galvanized Steel Coil PPGL

Prepainted Color Painted Galvanized Steel Coil PPGL

Prepainted Color Painted Galvanized Steel Coil PPGL
